RB2000 Barrier

Ideal for road and construction site safety
Compatible with mesh fence panels, hoarding and gates
Proven to withstand wind speeds of up to 72mph
Light and easy to move when empty
Creates a flat, solid wall when connected

Hire from£5.00per unit/week ex. VAT

Buy from£140.00per unit ex. VAT

Prices vary by quantity and delivery location

Product details

Hire or Buy
In-stock
Interlocking system
High visibility
Wind resistant

Key features

Height 1000mm
Depth 400mm
Width 1680mm
Weight 35kg
Filled Weight 400kg
Wind test classification Class A/72 mph

Applications

Construction sites
Events
Highway works

Download Spec Sheet

Download Install guide

Product ID: WFS150700

Hire or Buy
In-stock
Interlocking system
High visibility
Wind resistant

This is an excellent, low containment water filled barrier system. Before being filled with water, the barrier weighs just 35 kg and so can be moved with relative ease. Once the barriers are filled their weight is increased to 400kg.

The RB2000 Barrier has been wind tunnel tested at the prestigious Mira facility and proven to with stand high wind speeds both with and without mesh panels. As with other water filled barriers in the range, the RB2000 can be used with hoarding, mesh panels, vehicle, and pedestrian gates. When mesh and fence panels are added the overall height of the system is increased to 2.1m.

The barriers are designed with a patented five position interlocking system and can be positioned in straight lines and flows smoothly around bends and corners. Designed with a patented five position interlocking system, the barrier can be positioned to create a flat solid wall across uneven surfaces.

Benefits

Once the barriers are filled, they weigh up to 400kg and so very hard to move. They are made from prime polythene and can be used time and time again.

The wind tunnel testing demonstrated that three RB2000 Barriers were able to withstand wind speeds of up to 71mph, add a mesh fence panel to a barrier and it will continue resist wind speeds of up to 70 mph.

Additional safety lights may be mounted onto this water filled barrier system to ensure top level visibility. The barriers are also supplied in red and white as standard and front/end stops can be supplied to prevent trip hazards.

RB2000 barrier install guide:

The RB2000 Barriers are very straight forward to install, simply follow these steps:

Step 1 – Position the RB2000 barriers along the desired perimeter line. Lift the end of each barrier up and over the top of the neighbouring barrier. They should slot readily into place.

Step 2– Open the cap at the top of the barrier and fill with water, then replace the cap.

Step 3 – To insert mesh fence panels, position the panels over the top of the barriers so that poles line up with the holes at the top of the barriers. Gently slide the poles into position and check that they go through both the top holes on top of the barrier and mid-way through. Each mesh fence panel should line up with the panels next to it.

Step 4 – Next, add a coupler to the bottom and top section of the mesh fence panel. Secure the coupler in place using an impact driver or coupler spanner. Anti-tamper versions of the couplers are also available.

To empty the barriers, you need only to release the bung at the bottom of the barrier using the bung key.

Delivery options

These robust, heavy-duty barriers can be hired, purchased, delivered and installed nationwide. Contact us today for no obligation advice and a free project quote.
